Parameter

Short Description

Long Description

Angle (MEP)

Angle as defined in Route Specification

Relevant for circular duct elbows and pipe elbows. Defined in Route Specifications.

Branch Diameter (MEP)

Diameter of the branch segment

Relevant for circular branch segments of routes.

Defined in the Duct and Pipe Branch Default Set­tings dialog box under Segment.

Branch DN (MEP)

Nominal diameter of a branch

Relevant for circular branch segments of routes.

Defined in the Duct Default Settings dialog box under Dimensions.

Branch Height (MEP)

Height of the branch segment

Relevant for rectangular branch segments of routes.

Defined in the Duct and Cable Carrier Default Set­tings dialog box under Segment.

Branch Width (MEP)

Width of the branch segment

Relevant for rectangular branch segments of routes.

Defined in the Duct and Cable Carrier Default Set­tings dialog box under Segment.

Custom Angle Branch (MEP)

Real angle of the branch

Relevant for duct and pipe branches. Defined during the modeling of the branch.

Custom Angle Elbow (MEP)

Real angle of the elbow

Relevant for duct and pipe Elbows. Defined during the modeling of the bend.

Description (MEP)

Description of the segment

Relevant for rectangular and circular elbow, branch, transition, pipe, and duct segments of routes.

Defined in the Duct, Pipe and Cable Carrier Route Specifications in each table

Diameter (MEP)

Diameter of the segment or transition

Relevant for circular segments of routes or transi­tion element.

Defined in the Duct and Pipe Route Default Set­tings dialog box under Segment.

2nd Diameter (MEP)

For transitions: the second diameter

Relevant for transition element where the ends have varying diameters.

DN (MEP)

Nominal Diameter

Relevant for circular segments of routes. Defined in the Duct and Pipe Route Specification dialog under Reference Set.

2nd DN (MEP)

For transitions: the second nominal diam­eter

Relevant for transition element where the ends have varying dimensions.

Elbow Radius (MEP)

Radius of the elbow

Relevant for duct and pipe elbows. Defined in the duct and pipe specifications in the tab of the respective bends under Table of Dimensions

Height (MEP)

Height of the segment cross-section

Relevant for rectangular segments of duct routes or transition elements.

Defined in the Duct Settings dialog box under Seg­ment.

2nd Height (MEP)

For transitions: the second height

Relevant for transition element where the ends have varying height dimensions.

Insulation Thickness (MEP)

Thickness of the insulation

Relevant for circular and rectangular segments of routes.

Defined in the Duct and Pipe Route

Default Settings dialog box under Segment.

Length (MEP)

Length of the segment.

Relevant for rectangular and circular duct, pipe, and cable carrier segments of routes.

Defined during modeling input.

Material Name (MEP)

Name of the used Material

Relevant for rectangular and circular duct, pipe, and cable carrier segments of routes.

Defined in the Route Specification

MEP System

Attribute assigned to MEP route (e.g Fresh Air, Heating)

Relevant for all MEP Elements.
For Routes: Defined in the default settings dialog under MEP System.
For Accessory, Terminals and Equipments: Defined in element settings, on Connection tab page.

Slope (percentage) (MEP)

The steepness of the segment

Relevant to the route tools. Defined during route input.

Wall Thickness (MEP)

Thickness of the wall of the duct or pipe

For circular ducts and pipes: Defined in Route Specifications.
For rectangular ducts: Defined in the Duct Route Settings dialog box under Segment.

Width (MEP)

Width of the segment cross-section

Relevant for rectangular segments of duct routes.

Defined in the Duct Route Settings dialog box under Segment.

2nd Width (MEP)

For transitions: the second width

Relevant for transition element where the ends have varying width dimensions.
